Item:    RJ11 w/o shielded connector,female
Type:    SMT-1X1-6p6c
PCB mounting style:    SMT

Oriented:     top entry
Tab position:  tab up
Number of position/contacts:   6/6
Housing:   UL 94V-0
Material:    Glass-filled polyester  UL 94V-0
Standard color:    Black
Contact:   Phosphor bronze T=0.35mm
                Gold plating over nickel in contact area
Gold plating:  Selective gold plating
Shield: unshielded
Mehanical life time: 750 cycles min
Operating temperature range: -20°C to +75°C
Storage temperature range: -40°C to +85°C
